Harsh Metalloys, located in Mumbai, India, is a well-respected manufacturer and supplier of top-notch Stainless Steel Forged Flanges. These flanges are essential for creating secure and leak-proof pipe connections across various industries. Crafted through a hot forging process, they boast impressive strength, excellent pressure handling, and precise dimensions. We offer our forged flanges in stainless steel grades like 304, 316, 321, 310, and 904L, all adhering to international standards such as ASME B16.5, B16.47, and DIN. Our range includes different types—weld neck, slip-on, socket weld, blind, and threaded—catering to sectors like oil & gas, chemical, power, and marine.
Stainless Steel Forged Flanges are constructed from corrosion-resistant alloys, including SS 304, 316, and 904L, which typically have 18–25% Chromium and 8–22% Nickel. The 316 grade features 2–3% Molybdenum, enhancing its resistance to chlorides and pitting. These flanges deliver outstanding tensile strength (480–620 MPa) and yield strength (170–310 MPa), along with remarkable resistance to oxidation, thermal cycling, and corrosive environments. The forging process refines the grain structure and boosts mechanical integrity, making them ideal for high-pressure and high-temperature applications. Their machinability and weldability also make them perfect for custom-engineered piping systems.
Dimensions : ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
Size : 1/2″ (15 NB) to 48″ (1200NB)
Class : 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc.
DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636,DIN2637, DIN2638, DIN2673
BS : BS4504 , BS4504, BS1560, BS10
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Contact us to get a quick quote for your requirement.
We produce quality industrial products such as Stainless Steel Forged Flanges. Each one of them is made from top-of-the-line resources. They are what people all across the world trust. Our Stainless Steel Forged Flanges come in a variety of sizes and styles, including those made-to-order in line with particular requirements. Our mission is to supply trustworthy goods with the highest performance in fulfilling individual needs of our distinguished customers.
Stainless Steel Forged Flanges are resistant to corrosion but may corrode in extreme conditions, such as exposure to harsh chemicals, high temperatures, or salty environments, if not properly maintained.
Yes, Stainless Steel Forged Flanges are ideal for hygienic and sanitary applications due to their corrosion resistance, easy cleanability, and ability to withstand high temperatures, making them perfect for food and pharmaceutical industries.
Yes, Stainless Steel Forged Flanges can be fully recycled after use. Stainless steel is a highly recyclable material, retaining its properties even after multiple recycling processes, making it eco-friendly and sustainable.
To select the right Stainless Steel Forged Flanges, consider factors like material grade, pressure rating, temperature, environment, and compatibility with piping systems to ensure optimal performance and durability.
Stainless Steel Forged Flanges are widely used for connecting pipes, valves, pumps, and other equipment in systems that require secure sealing and strength under pressure. Common in industries such as oil & gas, petrochemicals, water treatment, pharmaceuticals, and shipbuilding, these flanges are ideal for both above-ground and underground pipeline networks. Weld neck flanges are preferred for high-stress applications, while slip-on and socket weld types suit low-pressure environments. Their resistance to corrosion and extreme temperatures makes them suitable for steam lines, chemical plants, and offshore platforms. Stainless steel forged flanges ensure long-lasting performance in critical and corrosive service conditions.
