Home > Stainless Steel Angles
Harsh Metalloys, Mumbai, India, is a leading manufacturer and supplier of Stainless Steel Angles, providing high-strength, corrosion-resistant structural elements for diverse industrial uses. Our stainless steel angles are carefully engineered in equal and unequal profiles, and can be supplied in various grades and sizes to satisfy both domestic and international markets. Characterized by their long life, superb finish, and flexibility, our angles have very widespread applications in construction, fabrication, and infrastructure development. Harsh Metalloys is dedicated to providing consistent quality, prompt service, and tailor-made solutions to fulfill the structure requirements of our varied customers in India and overseas.
Harsh Metalloys produces Stainless Steel Angles generally by using grades such as 304, 304L, 316, and 316L that have 16–20% chromium, 8–13% nickel, and up to 3% molybdenum (in 316 grades) to ensure better corrosion resistance. These angles provide mechanical characteristics like tensile strength of 485–620 MPa and good weldability and formability. They are resistant to structural breakdown due to high pressure and temperature and are available in hot-rolled and cold-drawn finishes. Harsh Metalloys guarantees accurate dimensional tolerance and a surface finish, which makes them suitable for structural and ornamental uses.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
At Harsh Metalloys, our stainless steel corners undergo rigorous testing to ensure quality and meet international standards. Certified for strength, durability and corrosion resistance, our products meet ISO and ASTM standards. Each batch is tested for chemical composition, mechanical properties and dimensional accuracy to ensure reliability and customer satisfaction.
Stainless Steel Angles provide strength, durability, and corrosion resistance, best suited for structural frameworks, support applications, and architectural designs in different industrial settings.
Stainless Steel Equal Angle has two sides of the same length, offering symmetrical support and stability in construction, fabrication, and reinforcement uses.
Stainless Steel Unequal Angle has sides of varied lengths, providing flexible structural support for applications needing unequal load distribution or special design needs.
Stainless Steel L Angle offers corrosion-resistant, heavy-duty support in an L-profile shape, often employed for brackets, frames, and structural members.
SS T-Bar Angles consist of horizontal and vertical components, providing superior load-bearing capability and corrosion resistance for architectural, structural, and industrial applications.
Stainless Steel Corner Angles guard and reinforce edges and corners, offering corrosion resistance and durability in construction, fabrication, and finishing processes.
