Harsh Metalloys is a reputed manufacturer and supplier of Stainless Steel 316/316L Angles based in Mumbai, India. Known for their exceptional corrosion resistance and strength, these stainless steel angles are widely used in structural and architectural applications. Grade 316 offers excellent resistance to pitting and crevice corrosion in chloride environments, while 316L features a lower carbon content, providing improved weldability and resistance to sensitization. Our SS 316/316L angles are fabricated in compliance with global standards like ASTM A276 and are available in a variety of sizes and finishes, catering to diverse industrial and marine construction requirements.
Stainless Steel 316/316L Angles are composed primarily of chromium (16–18%), nickel (10–14%), and molybdenum (2–3%). The presence of molybdenum enhances their corrosion resistance, especially in chloride-rich and marine environments. Grade 316 has higher tensile strength and creep resistance, while 316L has reduced carbon content, making it ideal for welding without the risk of carbide precipitation. These angles offer tensile strengths around 515 MPa and yield strengths of approximately 205 MPa. They maintain excellent formability, toughness, and strength even at cryogenic and elevated temperatures.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
We conducts a strict quality test and obtains certifications to guarantee the best Stainless Steel 316/316L Angles in terms of strength, corrosion resistance, and accuracy. Each product batch is certified for compliance with international standards and offers clients full assurance in terms of reliability, performance, and conformity to industrial needs for a variety of uses.
Stainless Steel 316/316L angles are L-shaped structural components known for their excellent corrosion resistance, strength, and durability. They are used in marine, chemical, and high-temperature applications for support and reinforcement.
Stainless Steel 316/316L equal angles have two legs of the same length, forming a 90-degree angle. They offer high strength and corrosion resistance, ideal for structural support in demanding environments.
Stainless Steel 316/316L unequal angles have legs of different lengths, creating a 90-degree angle. They provide versatile support and reinforcement in construction and industrial applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L L angles are L-shaped structural components offering high strength, durability, and superior corrosion resistance. They are used for framing and support in marine, chemical, and high-temperature environments.
SS 316/316L T-bar angles are stainless steel sections with a T-shaped profile, providing robust support and stability. They are ideal for structural and framework applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L corner angles are L-shaped sections designed for reinforcing and joining corners. They offer high strength, durability, and excellent corrosion resistance, making them suitable for construction and architectural applications.
Stainless Steel 316/316L Angles are extensively used in construction, structural supports, frames, braces, and reinforcements due to their high strength and corrosion resistance. Their non-reactive nature makes them suitable for use in food processing, pharmaceuticals, and chemical handling systems. These angles are also ideal for marine applications, architectural trims, and offshore platforms where resistance to saltwater and harsh weather is critical. Industries like oil & gas, power plants, petrochemicals, and wastewater treatment rely on SS 316/316L angles for their durability and long service life. Harsh Metalloys provides precision-cut angles in various lengths and thicknesses tailored to customer specifications.
