Harsh Metalloys, based in Mumbai, India, stands out as a leading manufacturer and supplier of high-quality Stainless Steel 304/304L Angles. These angles are celebrated for their remarkable strength, resistance to corrosion, and versatility. Crafted from the finest raw materials, they adhere to international standards such as ASTM A276 and ASTM A484. The dual-grade material merges the excellent corrosion resistance of 304 stainless steel with the enhanced weldability of its low-carbon variant, 304L. Offered in a range of sizes, thicknesses, and finishes, our SS angles are perfect for structural, architectural, and industrial uses. At Harsh Metalloys, we prioritize precision, durability, and prompt delivery for every order.
Stainless Steel 304/304L Angles consist of Chromium (18–20%), Nickel (8–12%), Carbon (≤0.08% for 304, ≤0.03% for 304L), Manganese (≤2%), Silicon (≤1%), Phosphorus (≤0.045%), and Sulfur (≤0.03%). These angles boast impressive mechanical properties, including a tensile strength ranging from 485 to 620 MPa, yield strength between 170 and 205 MPa, elongation of 35 to 40%, and hardness levels reaching 90 to 95 HRB. The lower carbon content in 304L helps prevent carbide precipitation during welding, maintaining structural integrity. These characteristics make them ideal for load-bearing applications, environments prone to corrosion, and high-fabrication settings.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
At Harsh Metalloys, all stainless steel 304/304L faces are rigorously tested to ensure quality and reliability. Certified to international standards, our products come with material test reports (MTR), third-party inspection certificates, and compliance with ASTM/ASME specifications. This ensures optimal performance, security and customer reliability in any application.
Stainless Steel 304/304L angles are L-shaped structural sections offering high strength, corrosion resistance, and durability. They are used in construction, manufacturing, and architectural applications for support and reinforcement.
Stainless Steel 304/304L equal angles feature two legs of the same length, forming a 90-degree angle. They provide strong, durable support and are widely used in construction and structural applications.
Stainless Steel 304/304L unequal angles have legs of different lengths, forming a 90-degree angle. They offer versatile support and reinforcement in construction and industrial applications, with high strength and corrosion resistance.
Stainless Steel 304/304L L angles are L-shaped structural components used for framing and support. They provide high strength, durability, and corrosion resistance, suitable for construction, manufacturing, and architectural applications.
SS 304/304L T-bar angles are stainless steel sections with a T-shaped profile. They provide robust support and stability for structural and framework applications, offering high strength, durability, and corrosion resistance.
Stainless Steel 304/304L corner angles are L-shaped sections designed to reinforce and join corners. They offer high strength, durability, and corrosion resistance, ideal for construction and architectural applications.
Stainless Steel 304/304L Angles are a go-to choice in construction, infrastructure, and fabrication projects, thanks to their impressive strength and resistance to corrosion. You’ll often find them in building frameworks, support structures, brackets, reinforcements, and machinery frames. In industries like food processing, chemicals, and pharmaceuticals, these angles are essential for equipment where hygiene and corrosion resistance are a must. They’re also perfect for marine and coastal applications, as they can handle salty environments with ease. Plus, they shine in architectural trims, transportation systems, and HVAC frameworks, providing reliability, low maintenance, and a long lifespan.
